Standex Electronics, Inc._A63-APS360-LACB1E
Standex Electronics, Inc._A63-APS360-LACB1E
Standex Electronics, Inc.

A63-APS360-LACB1E

Sensors
Standex Electronics, Inc.
A63-APS360-LACB1E
54-A63-APS360-LACB1E
Standex Electronics, Inc.-A63-APS360-LACB1E-datasheet-796035.pdf
Standex Electronics, Inc.-A63-APS360-LACB1E-datasheets-796035.pdf
ANGLE POSITION SENSOR - BARREL,
In Stock : 6

Not available

QUICK RFQ
ADD TO RFQ LIST
ampheo flow
  • Quantity
  • Unit Price
  • Ext. Price
    • 1+
    • $139.41000
    • $139.41
    • 10+
    • $126.34200
    • $1263.42
    ADD TO CART
    QUICK ORDER
    $139.41000    $139.41
    Description Tech Specifications Documents Shopping Guide

    A63-APS360-LACB1E Description

    ANGLE POSITION SENSOR - BARREL,

    Tech Specifications

    PCB changed
    4
    HTS
    8536.41.00.60
    Output Type
    Analog
    ECCN (US)
    EAR99
    Resistance Tolerance
    -
    PPAP
    No
    Product Status
    Active
    Automotive
    No
    Supplier Device Package
    -
    Minimum Operating Temperature (°C)
    -40
    Maximum Operating Temperature (°C)
    110
    Rotation Angle - Electrical, Mechanical
    0° ~ 360°
    Minimum Output Voltage (V)
    0
    Package / Case
    Barrel, Aluminum
    Technology
    -
    Voltage - Supply
    8V ~ 32V
    Output
    Analog Voltage
    REACH Status
    REACH Unaffected
    Package Height
    19.05
    Mfr
    Standex-Meder Electronics
    Maximum Operating Supply Voltage (V)
    32
    EU RoHS
    Compliant
    RoHS Status
    ROHS3 Compliant
    Moisture Sensitivity Level (MSL)
    Not Applicable
    Linearity Error (%)
    ±1
    Operating Temperature
    -40°C ~ 110°C
    Termination Style
    Cable with Connector
    Actuator Type
    -
    For Measuring
    Angle
    Vibration Rating (g)
    10
    Package Length
    44.45
    Mounting Type
    Panel Mount
    Mechanical Travel
    360°
    Pin Count
    4
    Mounting
    Panel
    Shock Rating (g)
    100
    Series
    -
    Type
    Linear
    Output Signal
    Programmable
    Linearity
    ±1%
    Part Status
    Active
    Package
    Bulk
    Package Width
    21.98
    Linear Range
    -

    A63-APS360-LACB1E Documents

    Download datasheets A63-APS360-LACB1E
