NXP Semiconductors
MPX2200DP
Sensors
MPX2200DP
54-MPX2200DP
SENSOR 29.01PSID 0.19" .04V
In Stock : 117
Not available
QUICK RFQ
ADD TO RFQ LIST
- 1+
- $18.58800
- $18.59
- 10+
- $16.46320
- $164.63
- 100+
- $15.93220
- $1593.22
- 1000+
- $14.87004
- $14870.04
ADD TO CART
QUICK ORDER
$18.58800
$18.59
MPX2200DP Description
NXP Semiconductors MPX2200 Serie
Tech Specifications
Operating Pressure
29.01PSI (200kPa)
Unit Weight
0.178410 oz
Device Pressure Type
Differential
PPAP
No
Pressure Type
Differential
Product Status
Active
RoHS
RoHS Compliant
Automotive
No
Port Type
Dual Radial Barbed
Supplier Package
Case 344C-01
Typical Full Scale Output
0.04V
Package / Case
4-SIP Module
Voltage - Supply
10V ~ 16V
REACH Status
REACH Unaffected
Response Time (ms)
1
Maximum Operating Supply Voltage (V)
16
EU RoHS
Compliant
Moisture Sensitivity Level (MSL)
Not Applicable
Operating Temperature
-40°C ~ 125°C
Termination Style
PC Pin
Port Size
Male - 0.19" (4.93mm) Tube, Dual
Media
Air
ECCN
EAR99
Mounting Type
Through Hole
Operating Pressure Range
0kPa to 200kPa
Pin Count
4
Mounting
Through Hole
Typical Operating Supply Voltage (V)
10
HTSUS
9026.20.4000
Package
Tray
USHTS
9026204000
Maximum Overload Pressure
800kPa
PCB changed
4
HTS
MPX2200DP
Output Type
Wheatstone Bridge
ECCN (US)
EAR99
Port Style
Barbed
Supply Voltage - Min
1 V
Supplier Device Package
-
Minimum Operating Temperature (°C)
-40
Maximum Operating Temperature (°C)
125
Accuracy
±0.25%
Operating Supply Current
6 mA
Output
0 mV ~ 40 mV (10V)
Package Height
29.34(Max)
Mfr
NXP USA Inc.
Features
Temperature Compensated
Maximum Operating Temperature
+ 125 C
Supply Voltage - Max
16 V
RoHS Status
ROHS3 Compliant
Mounting Style
Through Hole
Applications
Board Mount
Equivalent Overload Pressure Range (psi)
100 to 500
Package Length
29.85(Max)
Maximum Supply Current (mA)
6(Typ)
Minimum Operating Temperature
- 40 C
Series
MPX2200
Operating Supply Voltage
10 V
Part Status
Active
Package Width
11.05(Max)
Maximum Pressure
116.03PSI (800kPa)
Base Product Number
MPX2200
Minimum Operating Supply Voltage (V)
1
MPX2200DP Documents
Download datasheets MPX2200DP
